7 Data transfer
52 Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7 Data transfer
EtherNet/IP uses CIP™ (Common Industrial Protocol) for the data exchange between devices via an
Ethernet network – just like the closely related bus systems DeviceNet and ControlNet.
Lenze implements the CIP following the ODVA standard (Open DeviceNet Vendor Association,
www.odva.org
) and supports the two main types of EtherNet/IP communication:
• Explicit messaging (for parameter data)
• Implicit messaging (for I/O data)
