Lenze EtherNet/IP 8400 User Manual

Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17 139
14 Implemented CIP™ objects
14.2 EtherNet/IP objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.2.2 Quality of Service (QoS) Object (72 / 0x48)
The "Quality of Service (QoS) Object" enables different classifications and prioritisations of the data
packets for EtherNet/IP communication. For this purpose, the EtherNet/IP messages are marked
with "802.1Q tags" and "Differentiated Services Codepoints" (DSCP).
Class attributes
Instance attributes
The instance attributes act independently of each other.
The DSCP values are used for the IP headers.
Irrespective of this, VLAN tagging can be activated in addition (C13021
=1).
The VLAN ID of Lenze devices is ’0’.
The VLAN priority results from the DSCP values configured.
Changes in the attribute values will only take effect after a reset of the device ("power off/on" or
"type 0 reset").
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 1 (0x0001)
2 Get Max. Instance UINT 1 (0x0001)
3 Get Number of Instances UINT 1 (0x0001)
6 Get Max. ID Number Class
Attributes
UINT 7 (0x0007)
7 Get Max. ID Number Instance
Attributes
UINT 8 (0x0008)
 Note!
Before activating VLAN tagging, please ensure that all involved components support
VLAN tagging. It may occur that the devices not supporting VLAN tagging cannot be
accessed anymore.
Attribute
ID
Service Name Data type Value
1 Set 802.1Q Tag Enable USINT Enables the sending of data packets with
802.1Q tags (C13021
)
• 0: No use of 802.1Q tags (Lenze setting)
• 1: Use of 802.1Q tags
4 Set DSCP Urgent USINT 55: Urgent/imperative messages
Is not supported at the moment.
5 Set DSCP Scheduled USINT 47: Scheduled messages
(Can only be used for "exclusive owner"
connections.)
(C13022/4
)
6 Set DSCP High USINT 43: Messages with high priority
(Can only be used for "input only" and "listen
only" connections.)
(C13022/5
)
