5 Installation
5.2 Electrical installation
28
Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
•Tree via switches
[5-6] Tree topology (S = scanner, SW = switch)
•Switch / switch
[5-7] Switch / switch topology (SW = switch)
E94AYCEO006
S
SWSWSW
E94AYCEO007
SW
SWSW
