3.2 General data/operating conditions
Field Values
Vibration resistance Germanischer Lloyd, general conditions
Permissible moisture Humidity class F without condensation
(average relative humidity 85 %)
Permissible temperature ranges during transport: -25 °C ... +70 °C
during storage of the controller: -25 °C ... +55 °C
during operation of the controller: 0 °C ... +40 °C without derating
+40 °C ... +55 °C with power derating (controllers 9321-9326)
+40 °C ... +50 °C with power derating (controllers 9327-9332)
Permissible installation height h h ≤ 1000 m a.m.s.l. without derating
1000 m a.m.s.l. < h
≤ 4000 m a.m.s.l. with derating
Permissible pollution VDE 0110 part 2 pollution degree 2
Noise emission Requirements to EN 50081-2, EN 50082-1, EN 61800-3
Limit value class A to EN 55011 (industrial area) with mains filter A
Limit value class B acc. to EN 55022 (residential area) with mains filter B and installation in control cabinet
Noise immunity Limit values maintained using mains filter.
Requirements to EN 50082-2, EN 61800-3
Requirements Standard Severity
Running time EN61000-4-2 3, i.e. 8 kV at air discharge and 6 kV at contact discharge
RF interference
(enclosure) EN61000-4-3 3, i.e. 10 V/m; 27 to 1000 MHz
Burst EN61000-4-4 3/4, i.e. 2 kV/5 kHz
Surge IEC 1000-4-5 3, i.e. 1.2/50
µs, 1 kV phase-phase, 2 kV phase-PE
Insulation strength Overvoltage category III to VDE 0110
Packaging to DIN 4180
9321 to 9332: Delivery packing
Type of protection IP20
IP41 on the heat-sink side for thermal separation (punching)
NEMA 1: Protection against contact
Approvals CE: Low-Voltage Directive
UL508: Industrial Control Equipment
UL508C: Power Conversion Equipment
