Lenze i550 Series - Page 183

Inverter i550-C3.0/400-3 i550-C4.0/400-3 i550-C5.5/400-3 i550-C7.5/400-3
Rated power kW P
N
4 5.5 7.5 11
Rated power hp P
N
5 7.5 10 15
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0-400/480 V
Rated mains current
without mains choke A I
r, AC
8.6 11.2 15.3 22
with mains choke A I
r, AC
6.8 8.8 12.1 17.2
Apparent output power kVA A
ON
5.9 8 10.5 15
Rated output current
2 kHz A I
OUT
7.6 9.8 13.2 18.3
4 kHz A I
OUT
7.6 9.8 13.2 18.3
8 kHz A I
OUT
- - - -
16 kHz A I
OUT
- - - -
Power loss
2 kHz W 94 125 163 238
4 kHz W 100 133 173 253
8 kHz W - - - -
16 kHz W - - - -
at inverter disablecontroller
inhibit
W 6 6 6 6
Overcurrent cycle 180 s
Max. output current A I
max, out
9.5 12.3 16.5 21
Overload me s t
ol
60 60 60 60
Recovery me s t
re
120 120 120 120
Max. output current during the
recovery me
A 4.8 6.2 8.3 10.5
Overcurrent cycle 15 s
Max. output current A I
max, out
12.6 16.4 22 28
Overload me s t
ol
3 3 3 3
Recovery me s t
re
12 12 12 12
Max. output current during the
recovery me
A 4.7 6.2 8.3 10.5
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current A I
max, 1
9.5 16.6 16.6 29
Min. brake resistance Ω R
min
82 47 47 27
Max. motor cable length shielded
without EMC category m 100 100 100 100
Category C1 (2 kHz, 4 kHz, 8
kHz)
m - - - -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 20 20 20 20
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 35 35 50
Weight kg 2.3 2.3 2.3 3.7
Weight lb 5 5 5 8
Technical data
3-phase mains connecon 480 V "Light Duty"
Rated data
183
