Terminal data
Mains connecon
Inverter i550-C0.25/120-1 i550-C0.37/120-1 i550-C0.75/120-1 i550-C1.1/120-1
Connecon X100
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 2.5 2.5 6 6
Max. cable cross-secon AWG 12 12 10 10
Stripping length mm 8 8 8 8
Stripping length inch 0.32 0.32 0.32 0.32
Tightening torque Nm 0.5 0.5 0.7 0.7
Tightening torque lb-in 4.4 4.4 6.2 6.2
Required tool 0.5 x 3.0 0.6 x 3.5
PE connecon
Inverter i550-C0.25/120-1 i550-C0.37/120-1 i550-C0.75/120-1 i550-C1.1/120-1
Connecon PE
Connecon type PE screw
Max. cable cross-secon mm² 6 6 6 6
Max. cable cross-secon AWG 10 10 10 10
Stripping length mm 10 10 10 10
Stripping length inch 0.39 0.39 0.39 0.39
Tightening torque Nm 2 2 2 2
Tightening torque lb-in 18 18 18 18
Required tool Torx 20
Motor connecon
Inverter i550-C0.25/120-1 i550-C0.37/120-1 i550-C0.75/120-1 i550-C1.1/120-1
Connecon X105
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 2.5 2.5 2.5 2.5
Max. cable cross-secon AWG 12 12 12 12
Stripping length mm 8 8 8 8
Stripping length inch 0.32 0.32 0.32 0.32
Tightening torque Nm 0.5 0.5 0.5 0.5
Tightening torque lb-in 4.4 4.4 4.4 4.4
Required tool 0.5 x 3.0
The terminal data for the terminal X1 can be found under:4Terminal data ^ 72
Brake resistors
Inverter Brake resistor
Order code Rated resistance Rated power Thermal capacity Dimensions (h x b x
t)
Weight
Ω W kWs mm kg
i550-C0.25/120-1
ERBM180R050W 180 50 7.5 175 x 21 x 40 0.28
i550-C0.37/120-1
i550-C0.75/120-1
ERBP047R200W 47 200 30 320 x 41 x 122 1
i550-C1.1/120-1
Technical data
1-phase mains connecon 120 V
Brake resistors
