Lenze i550 Series - Page 4

Informaon on electrical installaon 46
Important notes 46
Preparaon 48
Mains connecon 49
1-phase mains connecon 120 V 50
1-phase mains connecon 230/240 V 51
3-phase mains connecon 230/240 V 53
3-phase mains connecon 400 V 55
3-phase mains connecon 400 V "Light Duty" 55
3-phase mains connecon 480 V 56
3-phase mains connecon 480 V "Light Duty" 56
Motor connecon 57
Connecon to the IT system 58
Connecon of motor temperature monitoring 60
Brake resistor connecon 61
DC-bus connecon 62
Control connecons 62
Networks 63
CANopen 63
EtherCAT 63
EtherNet/IP 64
Modbus RTU 64
Modbus TCP 65
POWERLINK 65
PROFIBUS 66
PROFINET 67
Funconal safety 68
Important notes 69
Basic Safety - STO 70
Connecon diagram 71
Terminal data 72
Contents
4
