Installation
Electrical installation
Use of plug connectors
5
31
EDS82ZAFPC010 EN 4.0
5.2.6 Use of plug connectors
Stop!
Observe the following to prevent any damage to plug connectors and
contacts:
ƒ Only pug in / unplug the plug connectors when the controller is
disconnected from the mains.
ƒ Wire the plug connectors before plugging them in.
ƒ Unused plug connectors must also be plugged in.
Use of plug connectors with spring connection
E82ZAFX013
