5.3 Bus cable length
Max. possible bus cable length
The following bus cable lengths are possible in dependence on the baud rate and the cable
used:
Baud rate [kbit/s] Thin Cable Thick Cable
125
100 m
500 m
250 250 m
500 100 m
When using both, Thick" and Thin" cables, the maximum cable lengths are to be selected
according to the baud rate:
Baud rate [kbit/s] Bus cable length
125 L
max
= 500 m = L
thick
+ 5 L
thin
250 L
max
= 250 m = L
thick
+ 2.5 L
thin
500 L
max
= 100 m = L
thick
+ L
thin
