Lenze L-force PROFIBUS-DP User Manual

Codes
Overview
10

69
EDS82ZAFPC010 EN 4.0
10 Codes
10.1 Overview
Code Subcode Index Designation See
C0002 − 24573
d
=
5FFD
h
Parameter set management  84
C0126 − 24449
d
=
5F81
h
Behaviour with communication error  75
C1500 − 23075
d
=
5A23
h
Software identification code  77
C1501 − 23074
d
=
5A22
h
Software creation date  77
C1502 1 ... 4 23073
d
=
5A21
h
Display of software identification code  77
C1503 1 ... 4 23072
d
=
5A20
h
Display of software creation date  77
C1509 − 23066
d
=
5A1A
h
Setting the station address  71
C1510 − 23065
d
=
5A19
h
Configuration of process input data  72
C1511 − 23064
d
=
5A18
h
Configuration of process output data  73
C1512 − 23063
d
=
5A17
h
Enable process output data  74
C1513 − 23062
d
=
5A16
h
Monitoring response time of PZD
communication
 76
C1514 − 23061
d
=
5A15
h
Monitoring reaction in case of PZD
communication fault
 76
C1516 − 23059
d
=
5A13
h
Display of baud rate  78
C1517 − 23058
d
=
5A12
h
Display of station address  78
C1520 1...10 23055
d
=
5A0F
h
Display of all words to master  79
C1521 1...10 23054
d
=
5A0E
h
Display of all words from master  79
C1522 1...16 23053
d
=
5A0D
h
Display of all process data words to basic
device
 79
C1523 1...16 23052
d
=
5A0C
h
Display of all process data words from
basic device
 80
C1526 1...3 23049
d
=
5A09
h
Display of last configuration data  81
C1530 − 23045
d
=
5A05
h
PROFIBUS−DP diagnostics  82
C1531 1 ... 4 23044
d
=
5A04
h
Bus status  83
