Lenze L-force PROFIBUS-DP User Manual

Codes
Monitoring codes
10

76
EDS82ZAFPC010 EN 4.0
C1513: Monitoring response time of PZD communication
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1513 23062
d
=
5A16
h
3000 0 [1 ms] 65535 FIX32
The value of the response monitoring time is provided by the master.
 Note!
A change in the monitoring time becomes effective immediately.
Monitoring starts with the receipt of the first telegram.
The setting C1513 = 0 deactivates the monitoring function.
C1514: Monitoring reaction in case of PZD communication fault
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1514 23061
d
=
5A15
h
0
0 [1] 3
FIX32
0: no action
1: TRIP (fault)
2: controller inhibit (CINH)
3: quick stop (QSP)
If the master does not send a message within the response monitoring time (configurable
in C1513), the action set in this code is executed.
 Note!
A change in the monitoring reaction becomes effective immediately.
