Parameter data transfer
DRIVECOM parameter data channel
Reading parameters
8

63
EDS82ZAFPC010 EN 4.0
Result:
ƒ Request telegram from master to drive:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
01
hex
00
hex
5F
hex
C2
hex
00
hex
00
hex
00
hex
00
hex
00000001
bin
00000000
bin
01011111
bin
11000010
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
Waiting for change of handshake bit in the response (bit 6 here: 0 à 1)
ƒ Response telegram from drive to master (for error−free execution):
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
30
hex
00
hex
5F
hex
C2
hex
00
hex
06
hex
8F
hex
B0
hex
00110000
bin
00000000
bin
01011111
bin
11000010
bin
00000000
bin
00000110
bin
10001111
bin
10110000
bin
