Parameter data transfer
DRIVECOM parameter data channel
Writing parameters
8

65
EDS82ZAFPC010 EN 4.0
Result:
ƒ Request telegram from master to drive:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
72
hex
00
hex
5F
hex
F3
hex
00
hex
03
hex
0D
hex
40
hex
01110010
bin
00000000
bin
01011111
bin
11110011
bin
00000000
bin
00000011
bin
00001101
bin
01000000
bin
Waiting for change of handshake bit (bit 6 here: 0 à 1)
ƒ Response telegram from drive to master (for error−free execution):
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
40
hex
00
hex
5F
hex
F3
hex
00
hex
00
hex
00
hex
00
hex
01000110
bin
00000000
bin
01011111
bin
11110011
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
Waiting for change of handshake bit (bit 6 here: 1 à 0)
