Installation and commissioning
DIGIDRIVE
Variable speed drive
32
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
3.5.8 - Conformity to standards
Tests carried out in conditions imposed by the standards demonstrate that, providing they are
installed and connected in accordance with the instructions in paragraphs 3.5.5 and 3.5.7,
DIGIDRIVE units conform to the EMC directive 89/336/EEC modified by 92/31/EEC.
3.5.8.1 - Immunity
DIGIDRIVE units conform to international immunity standards.
3.5.8.2 - Conducted emissions
When used with the associated filters, DIGIDRIVE units conform to the standards relating to
conducted emissions in the conditions indicated below.
Conducted emissions with Type 1 filter (for filter characteristics see section 7.1)
Standards Type of immunity Application Level
EN 50082-1
Generic immunity standard
- Conforms
Part 1: residential, commercial
and light industry
EN 50082-2
Generic immunity standard
- Conforms
Part 2: industrial environment
EN 61800-3
Variable speed drive standard Conforms to the first and second environment
IEC 61800-3
Symbols Standards Description Application
R
EN 50081-1
Generic emission standard
A.C. supplyfor residential, commercial
and light industry environments
EN 61800-3
Variable speed drive standard
Conforms to the first and second
IEC 61800-3 environments
I
EN 50081-2
Generic emission standard A.C. supply
for industrial environments
EN 61800-3
Variable speed drive standard
Conforms to the first and second
IEC 61800-3 environments
# Requires special technology: please consult LEROY-SOMER
Ratings Voltage Filters
Length of motor cables
(m)
Switching frequency
3 kHz 6 kHz 12 kHz
0.5M to 1.5M 1-ph 230V FLT 5594 - 12 1 to 20 R R I
1.5M/TL to 3.5M/TL 1-ph 230V FLT 5594 - 26
1 to 15 I I I
15 to 50 I # #
1.5M/TL to 3.5M/TL 3-ph 230V FLT 5901 - 17 1 to 15 I # #
5.5TL 3-ph 230V FLT 5901 - 30 1 to 20 I I I
1.5T to 5.5T 3-ph 400V FLT 5901 - 17 1 to 15 I # #
8TL and 11TL 3-ph 230V FLT 5901 - 30 1 to 15 I I #
8T and 11T 3-ph 400V FLT 5901 - 17 1 to 15 I I I
16T and 22T 3-ph 400V FLT 5901 - 33 1 to 15 I # #
27T 3-ph 400V FLT 5901 - 37 1 to 20 I # #
