Leroy-Somer DIGIDRIVE SE2.5T User Manual

Installation and commissioning
DIGIDRIVE
Variable speed drive
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
33
Conducted emissions with Type 2 filter (for filter characteristics see section 7.2)
Ratings Voltage Filters
Length of motor cables
(m)
Switching frequency
3 kHz 6 kHz 12 kHz
0.5M to 1.5M 1-ph 230V FLT 5581 - 12
1 to 5 R R R
5 to 20 R R I
20 to 50 R I I
50 to 75 I # #
1.5M/TL to 3.5M/TL 1-ph 230V FLT 5581 - 26
1 to 15 R R R
15 to 80 R R I
80 to 100 I I I
1.5M/TL to 3.5M/TL 3-ph 230V FLT 5569 - 16
1 to 45 R R R
45 to 100 R R I
5.5TL 3-ph 230V FLT 5569 - 26
1 to 20 R R I
20 to 45 I I I
45 to 100 I # #
1.5T to 5.5T 3-ph 400V FLT 5569 - 16
1 to 20 R R I
20 to 50 R I I
50 to 100 I # #
8TL and 11TL 3-ph 230V FLT 5569 - 30
1 to 20 R I I
20 to 100 I # #
8T and 11T 3-ph 400V FLT 5569 - 17
1 to 15 R R I
15 to 30 R I I
30 to 100 I # #
16T and 22T 3-ph 400V FLT 5569 - 33
1 to 20 R I I
20 to 100 I # #
27T 3-ph 400V FLT 5569 - 37
1 to 20 R R R
20 to 70 I I I
70 to 100 I I #
33T 3-ph 400V FLT 5113 - 50
1 to 10 R R R
10 to 50 I I I
50 to 100 I I #
40T 3-ph 400V FLT 5113 - 63
1 to 10 R R R
10 to 50 I I I
50 to 100 I I #
50T 3-ph 400V FLT 5113 - 100
1 to 10 R R R
10 to 50 I I I
50 to 100 I I #
