The levels of conducted emissions specified in standards EN 50081-1 and 50081-2 are
equivalent to the levels required by the following specific standards:
Conducted emissions from 150 kHz to 30 MHz
Generic standard Specific standard
EN 50081-1
EN 55011 Class B
Industrial, scientific and medical equipment
CISPR 11 Class B
EN 55014
Domestic electrical appliances
CISPR 14
EN 55022 Class B
Data processing equipment
CISPR 22 Class B
EN 50081-2
EN 55011 Class A Group 1
Industrial, scientific and medical equipment
CISPR 11 Class A Group 1
EN 55022 Class A
Data processing equipment
CISPR 22 Class A
3.5.8.3 - Radiated emissions
When the drive, associated with one of the
RFI filters listed in section 3.5.7, is installed
in a steel cabinet and the wiring
recommendations have been adhered to, it
meets the limits for radiated emissions
defined in the generic emission standard for
residential environments,
EN 50081-1 (0.5M to 1.5M ratings only) and
the generic emission standard - industrial
environment part EN 50081-2 (1.5M/TL to
50T ratings).
Tests have been carried out with an
enclosure representative of the most
common installations. It may be, on a
device with different characteristics,
that the levels of radiated emissions are
not identical to those identified during
tests.
The tables below summarise the radiated
emission results and indicate the six least
favourable measurements between 30 and
1000 MHz.
Note:
• Level authorised by standard EN 50081-1
at 10 m is 30 dBµV/m.
• Level authorised by standard EN 50081-2
is 40 dBµV/m.
DIGIDRIVE rating
Frequency
(MHz)
Emissions
(dBµV/m)
0.5M to 1.5M
48.75 24.0
48.85 24.0
48.95 24.2
49.10 24.1
49.25 23.9
49.55 23.7
DIGIDRIVE rating
Frequency
(MHz)
Emissions
(dBµ/m)
41.45 36.6
41.65 36.0
1.5M/TL to 5.5TL 40.4 35.9
1.5T to 5.5T 40.3 35.6
38 35.3
38.35 35.2
46.9 33.2
49.0 31.6
8TL and 11TL 46.45 27.8
8T and 11T 40.85 27.3
63.5 26.2
30.2 26.1
16T to 27T
44.75 25.1
45.0 25.3
45.25 25.1
44.25 25.5
31.65 24.4
32.15 24.4
30T to 50T
60.7 30
60.35 29.5
61.1 29.5
50.2 28.5
50.45 28.5
61.4 28.5
