Installation and commissioning
DIGIDRIVE
Variable speed drive
Réf. 3218 GB - 4.33 / d - 02.02
LEROY-SOMER
63
:Security code
Adjustment range : 0 to 9999
Factory setting : 0
This is used for entering a security code
preventing access to parameter-setting
mode. See parameter 1
1
0
0
.
The personal code can only be read when
it is being entered.
Do not use code 0.
To access a parameter, enter the personal
code in the parameter, when the drive
indicates "CodE" on the display.
:Enable the FWD/REV key
on the keypad
Adjustment range : OFF or On
Factory setting : OFF
OFF: FWD/REV key disabled.
On: enables the FWD/REV key on the
keypad.
:Keypad reference on
power-up
Adjustment range : 0, LASt, PrS1
Factory setting : 0
In keypad mode (5
5
: PAd) is used to select
the speed reference value on power-up.
0 : the reference is zero.
LASt: the reference corresponds to the last
value selected when the drive was powered
down.
PrS1: the reference corresponds to the
value of preset frequency 1.
:Copy parameters
Adjustment range : no, rEAD, Prog, Auto,
boot
Factory setting : no
no: no communication with the copy
key.
rEAD: transfers the parameters stored in
the copy key to the drive. To enable this
transfer, the drive must be locked, unlocked
or faulty and the user should reset the drive
( key).
When the data has been transferred,
parameter 2
2
8
8
returns to value "no".
Prog: transfers the drive parameters to the
copy key. To enable this transfer, reset the
drive ( key). When the data has been
transferred, parameter 2
2
8
8
returns to value
"no".
Auto: transfers the drive parameters to the
copy key.
Any modification of a parameter is then
automatically saved to the copy key.
boot: if, on power-up, a key is present and
2
2
8
8
has been saved as boot in the key, the
key parameters are automatically
transferred and stored in the drive memory.
Any modification of a parameter is then
automatically saved to the copy key.
• When installing or uninstalling
the copy key, switch off the drive.
CAUTION:
• When parameters are being
transferred to the copy key, parameter
2
2
8
8
should be stored as follows:
- if 2
2
8
8
= no, rEAd, Prog in the drive,
parameter 2
2
8
8
should be set to
" no " in the key
- if 2
2
8
8
= Auto or boot in the drive,
parameter 2
2
8
8
should be set to
"Auto" or "boot" in the key. Thus, if a
drive is powered up with a copy key, in
which 2
2
8
8
is stored as "boot", all the
parameters in memory in the key will be
instantly transferred to the DIGIDRIVE.
• The copy key can be used on drives of
different ratings, but the parameters
described below will not be copied, and
the drive will go into fault mode "C.rtg".
Press the key and check the
following parameters:
0
0
6
6
: Motor rated current.
0
0
8
8
: Motor rated voltage.
2
2
5
5
2
2
6
6
2
2
7
7
2
2
8
8
