Device description
Leuze electronic MLC 520 9
3 Device description
The safety sensors from the MLC500 series are active opto-electronic protective devices. They satisfy the
following standards:
MLC500
Type in accordance with ENIEC61496 4
Category in accordance with ENISO13849 4
Performance Level (PL) in accordance with ENISO13849‑1 e
Safety Integrity Level (SIL) in accordance with IEC61508 and SILCL in ac-
cordance with ENIEC62061
3
The safety sensor consists of a transmitter and a receiver (see chapter 3.1 "Device overview"). It is pro-
tected against overvoltage and overcurrent acc. to IEC60204-1 (safety class3). Its infrared beams are not
influenced by ambient light (e.g. welding sparks, warning lights).
3.1 Device overview
The series is characterized by three different receiver classes (Basic, Standard, Extended) with specific
features and properties (see table below).
Tab.3.1: Device models in the series with specific features and functions
Transmitter Receiver
Basic Standard Ex-
tended
MLC500
MLC501
MLC500/A MLC502 MLC510
MLC511
MLC510/A MLC520 MLC530
OSSDs (2x) ■ ■ ■
AS-i ■ ■
Transmission chan-
nel changeover
■ ■ ■ ■ ■
LED indicator ■ ■ ■ ■ ■ ■ ■
7‑segment display ■ ■
Automatic start/
restart
■ ■ ■
RES ■ ■
EDM ■
Linkage ■
Blanking ■
Muting ■
Scan mode ■
Range reduction ■
Test input ■
Protective field properties
The beam distance and the number of beams are dependent on the resolution and protective field height.
NOTICE
Depending on the resolution, the effective protective field height can be larger than the optically
active area of the safety sensor housed in yellow (see chapter 3.1 "Device overview" and see
chapter 14.1 "General specifications").
