1.3 SOLID-4 selection
SD4trr-hhhhvk
SOLID-4
t - Type of device
T: Transmitter
R: Receiver
rr - Resolution/range
14: 14 mm / 0.3 – 6 m
20: 20 mm / 0.7 – 14 m
30: 30 mm / 0.5 – 9 m
40: 40 mm / 0.9 – 20 m
90: 90 mm / 0.9 – 20 m
hhhh – Protective field heights
150 ... 1,800 mm
v – Functions (only with receiver)
E: With selectable start/restart interlock and monitoring
func
tion
k – Version/mode (only
available with function "E")l
Without
H
G
L
U
Standard model
Host
Guest
L-Shape
U-Shape
Fig. 1.3-1: Select
ing
a SOLID-4 Safety Light Curtain
