“User name of SMTP 2”, granted user name on the backup email server.
“Password of SMTP 2”, granted password on the backup email server.
“Recipient email address 2” The email address of the recipients for the backup
server.
“Sender email address”, the email address of the sender.
FTP
“Local FTP server port” This can be other than the default port 21. The user can
change this value from 1 to 65535. After the changed, the external FTP client
program must change the server port of connection accordingly.
“1st FTP server” The domain name or the IP address of the external FTP server.
The following user settings must be correctly configured for remote access.
“1st FTP user name” Granted user name on the external FTP server.
“1st FTP password” Granted password on the external FTP server.
“1st FTP remote folder” Granted folder on the external FTP server. The string
must conform to that of the external FTP server. Some FTP servers cannot
accept preceding slash symbol before the path without virtual path mapping.
Refer to the instructions for the external FTP server for details. The folder
privilege must be open for upload.
“Primary FTP passive mode” The Network Camera is located inside the network
protected by a firewall, data connection for FTP may be prohibited. By
selecting passive mode, the FTP can bypass the rule and allow snapshot
upload to proceed. If the passive mode is selected, the Network Camera can
automatically attempt for active mode, if the external FTP server does not
support passive mode.
“2nd FTP server” The domain name or IP address of the external FTP server.
“2nd FTP user name” Granted user name on the backup FTP server.
“2nd FTP password” Granted password on the backup FTP server.
“2nd FTP remote folder” Granted folder on the backup FTP server.
“Secondary FTP passive mode” Passive mode setting for the backup FTP server.
HTTP
“Http port” This can be other than the default Port 80. Once the port is changed,
