LevelOne FCS-4041 - Page 33

33
Advanced
 Web Server port
The default web server port is 80. Once the port is changed, the user must
be notified the change for the connection to be successful. For instance,
when the Administrator changes the HTTP port of the IP Camera whose
IP address is 192.168.0.100 from 80 to 8080, the user must type in the
web browser “http://192.168.0.100:8080” instead of “http://192.168.0.100”.
 RTSP port
The default setting of RTSP Port is 554; the setting range is from 1024 to
65535.
 MJPEG over HTTP port
The default setting of MJPEG over HTTP Port is 8008; the setting range is
from 1024 to 65535.
 HTTPS port
The default setting of HTTPS Port is 443; the setting range is from 1024 to
65535.
NOTE: Be aware to choose the different port from the one set for the
web server port.
IPv6 Address Configuration
With IPv6 support, users can use the corresponding IPv6 address for browsing.
Enable IPv6 by checking the box and click on <Save> to complete the setting.
