LevelOne FCS-5041 - Digital Output (DO)

- 54 -
http://ip_address/ notification.cgi?parameter
ip_address – type the IP address or host name of the HTTP host.
Parameter – type the notification parameter if necessary.
Example
URL -
http://192.168.1.1/xxxx.cgi
Message - name1=value1&name2=vlaue2
Result - http://192.168.1.1/xxxx.cgi? name1=value1&name2=vlaue2
Ex:
https://192.168.1.1/notification.cgi?event=MD&camera=FB-100A
Message - Enter the message notification that will be sent when an event is triggered.
Enter the user name and password if necessary.
Click Apply to apply settings or Cancel to cancel changes.
Digital Output (DO)
The DO socket allows the IP camera to send output to an external device. While executing the DO
notification action, the IP camera drives voltage on the connected DO wire to the triggering voltage
level for X number of seconds. The connected external device will then be triggered for X number of
seconds.
Triggered Voltage Level - OPEN or GROUND
Users should select the option according to the specification of their external device.
