5.1.4 Errors Display on the Integrated Panel
Error
Source
Errors
Error Code
on Display
Motor
No Motor
Er 01
Motor
Motor cable (power wires) not connected to controller
Er 02
Motor
Motor cable (sensor wires) not connected to controller
Er 03
Motor
No Rotor
Er 04
Controller
Short circuit
Er 05
Controller
Over current in the bearing coils
Er 06
Controller
Over current in the drive coils
Er 07
Controller
DC-Link voltage out of range (Voltage range for monitoring: 18 – 54 VDC)
If the voltage is out of extended range the system starts to reduce the speed and an error is
generated. When reaching 0 rpm and the voltage is still out of extended range the system is
disabled.
Er 08
Controller
Communication problems EEPROM Controller
Er 09
Motor
Communication problems EEPROM Motor
Er 10
Controller
Controller temp. over 80
0
C or more than 10 minutes above 70
0
C
Er 11
Motor
Motor temp. over 100
0
C or more than 10 minutes above 90
0
C
Er 12
Pump
Dry running of pump circuit:
-> Pump keeps running on reduced speed (5000 rpm)
-> The system accelerates to the original speed value when the pump is refilled with liquid.
-> Note that the speed is only reduced during dry running if the pump speed was ≥ 6000 rpm.
Blinking
dots on
display
Table 12: Errors and warnings with indication on display of LPC-200.1
Note 1: In case of an error the system can only be restarted with a reset or a power supply restart
Note 2: Description is for standard firmware.
Note 3: For other configurations of error codes refer to alternate controller or firmware documentation
