Levitronix BPS-2000.2 User Manual

User Manual for BPS-2000
www.levitronix.com
PL-4021-00, Rev02, DCO# 15-235
5
System Name
Article #
Pump Head
Controller
Standard
Firmware
Motor
Note
BPS-2000.1
BPS-2000.2
BPS-2000.4
BPS-2000.5
100-90479
100-90480
100-90482
100-90483
LPP-2000.6 (High Flow)
LPP-2000.6 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.7 (High Pressure)
LPC-2000.1-01
LPC-2000.2-01
LPC-2000.1-02
LPC-2000.2-02
E1.25
E1.48
E2.25
E2.48
LPM-2000.2
Adaptor/Extension (0.5 - 10m) cables according to Table 3 (position 4a
and 4b) have to be ordered as separate article with specified length.
Certifications: CE, IECEE (CB scheme), ETL (NRTL) -> see Section 9.1
BPS-2000.7 (ATEX)
BPS-2000.8 (ATEX)
BPS-2000.10 (ATEX)
BPS-2000.11 (ATEX)
100-90485
100-90486
100-90488
100-90489
LPP-2000.6 (High Flow)
LPP-2000.6 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.7 (High Pressure)
LPC-2000.1-01
LPC-2000.2-01
LPC-2000.1-02
LPC-2000.2-02
E1.25
E1.48
E2.25
E2.48
LPM-2000.8
(ATEX)
Adaptor/Extension (0.5 - 10m) cables according to Table 3 (Position 5a
and 5b) have to be ordered as separate article with specified length. ATEX
Cable Sealing System can be ordered according to Table 4 (Position 9).
Certifications: CE, IECEE (CB scheme), ETL (NRTL), ATEX and IECEx ->
see Section 9.1
Table 1: Standard system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
Pump Head
“High Flow Profile”
LPP-2000.6
100-90418
Impeller / Pump Housing
Reinforcing Housing
Sealing Ring / Fittings
PFA / PFA (wet parts)
PP + GF30
Kalrez

perfluoroelastomer
1

Max. Flow
Max. Diff. Pressure
Max. Viscosity/Max. Density
Max. Liquid Temperature
140 liters/min / 37 gallons/min
4.2 bar / 61 psi
80 cP / 1.8 g/cm
3
90
0
C / 194
0
F
1b
Pump Head
“High Pressure Profile”
LPP-2000.7
100-90419
Impeller / Pump Housing
Sealing Ring / Fittings
PFA / PTFE (wet parts
Kalrez

perfluoroelastomer
1

Max. Flow
Max. Diff. Pressure
Max. Viscosity/Max. Density
Max. Liquid Temperature
80 liters/min / 21 gallons/min
6.9 bar / 100 psi
100 cP / 1.8 g/cm
3
90
0
C / 194
0
F
2a
Motor
LPM-2000.2
100-10050
Housing
- ETFE (chemical resistant) coated Aluminum
- waterproofed (IP67 without connectors)
Cable / Connectors
2x 3m cables with FEP jacket / 2x circular (AMP types)
2b
Motor (ATEX)
LPM-2000.8
100-10060
ATEX / IECEx Marking
II 3G Ex nA IIC T5 Gc
II 3D Ex tc IIIC T100°C Dc
Cable / Connectors
2x 3m cables with FEP jacket / 2x circular (M23, IP67)
3a
Standalone
Controller
(User Panel)
LPC-2000.1-01
(“High Flow”)
LPC-2000.1-02
(„High Pressure“)
100-30018
(Supply and Enable
connector included)
100-30019
(Supply and Enable
connector included)
Voltage / Current / Power
1 x 200-240 V AC  10% / 1 x 13.3  11.1 A  10% / 2kW @ 50/60Hz
3 x 200-240 V AC  10% / 3 x 6.7  5.6 A  10% / 2kW @ 50/60Hz
See Section 3.2 for details.
Housing Protection
IP20
Interfaces for
Standalone Controller
Panel to set speed (automatic storage on internal EEPROM)
PLC with
1x analog  4 - 20 mA
 0 - 24 V (optocoupler)
 0 - 24 V (relais)
Firmware “High Flow“
Firmware “High Pressure”
E1.25 (standard firmware for “High Flow”)
E2.25 (standard firmware for “High Pressure”)
3b
Extended
Controller
(PLC and USB)
LPC-2000.2-01
(“High Flow”)
LPC-2000.2-02
(„High Pressure“)
100-30021
(Supply and PLC
connector included)
100-30022
(Supply and PLC
connector included)
Interfaces for
Extended Controller
PLC with
- up to 4 digital inputs 0 - 24V (optocoupler)
- up to 4 digital outputs 0 - 24 V (relais)
- up to 2 analog inputs 4 - 20mA
- up to 2 analog inputs 0  10 V
- up to 2 analog outputs 0  5 V
USB interface (for service and system monitoring)
Firmware “High Flow“
Firmware “High Press.”
E1.48 (standard firmware for “High Flow”)
E2.48 (standard firmware for “High Pressure”)
Table 2: Specification of standard components
1: Kalrez

is a registered trademark of DuPont Dow Elastomers
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
Sensor Cable
Power Cable
Sensor
Power
4a
4b
Extension Adaptor
Cable for Sensor (a)
and Power (b)
MCAS-600.1-05 (0.5m)
MCAS-600.1-30 (3m)
MCAS-600.1-50 (5m)
MCAS-600.1-70 (7m)
MCAS-600.1-100 (10m)
MCAP-2000.1-05
MCAP-2000.1-30
MCAP-2000.1-50
MCAP-2000.1-70
MCAP-2000.1-100
190-10122
190-10123
190-10124
190-10101
190-10125
190-10208
190-10210
190-10211
190-10205
190-10212
Jacket Material
Connector Types
Connector Material
PVC
Circular AMP to D-SUB (a)/COMBICON (b)
Plastics (PA)
5a
5b
Extension Adaptor
Cable for Sensor (a)
and Power (b)
MCAS-600.3-05 (0.5m)
MCAS-600.3-30 (3m)
MCAS-600.3-50 (5m)
MCAS-600.3-70 (7m)
MCAS-600.3-100 (10m)
MCAP-2000.3-05
MCAP-2000.3-30
MCAP-2000.3-50
MCAP-2000.3-70
MCAP-2000.3-100
190-10158
190-10159
190-10130
190-10160
190-10161
190-10219
190-10221
190-10222
190-10223
190-10224
Jacket Material
Connector Types
Connector Material
PVC
Circular M23 (IP-67) to D-SUB (a)/COMBICON (b)
Metallic  Nickel coated
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
6a
Air Cooling Module
ACM-4.2
190-10139
Material / Connection Port

Air Pressure / Air Consumption
~1 - 3 bar (14  43 psi) / 110 Liter/min = 3.8 SCFM @ 1 bar
6b
Air Cooling Module
ACM-4.3
190-10243
Material
PP-EL-S with conductive additive for operation with ATEX motor
7
(a-e)
Impeller Exchange Kit
IEK-2000.1
(for LPP-2000.7)
100-90529
Impeller (a) / O-Ring (b)
Pump Casing Screws (c)
Pump Motor Screws (d)
Imp. Exchange Tool IET-3.1 (e)
LPI-2000.1 in PFA / O-Ring, Kalrez

, 98.02 x 3.53
8pcs M8x40, Stainless Steel with PTFE coating
4pcs M8x30, Stainless Steel with PTFE coating
POM-C
8
(a-e)
Impeller Exchange Kit
IEK-2000.2
(for LPP-2000.6)
100-90530
Impeller (a)../..O-Ring (b)
Pump Casing Screws (c)
Pump Motor Screws (d)
Imp. Exchange Tool IET-3.1 (e)
LPI-2000.2 in PFA / O-Ring, Kalrez

, 98.02 x 3.53
8pcs M8x40, Stainless Steel with PTFE coating
4pcs M8x30, Stainless Steel with PTFE coating
POM-C
9
(a – f)
Ex Cable
Sealing System
ACS-A.1
(Roxtec)
100-90292
Sleeve (a) and Gasket (b)
Frame (c)
2x Cable Module (d)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (e) and measurement
plates (f) are included.
Table 4: Specification of accessories
