Parts catalog 7-71

7510

Assembly 54: 3TM covers

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3825 1 1 Tray module right cover

2 40X3824 1 1 Tray module foot cover

3 40X3826 2 1 Tray module left cover

4 40X3827 1 1 Tray module rear cover

5 40X3823 1 1 Tray module top cover
