Lexmark 940e - Assembly 65: TTM Left Door

To Next Page

To Previous Page

7-88 MFP Service Manual

7510

Assembly 65: TTM left door

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3844 1 1 TTM left door assembly (this comes assembled)

2 40X3821 1 1 Switch (tray module left door interlock)
