Page #37 background imageLoading...
Page #37 background image
Use the To
5 Security lock port Lock the system controller board.
6 Printer power cord socket Connect the printer to a properly grounded electrical outlet.
Networking
Notes:
Purchase a MarkNet
TM
N8352 wireless network adapter first before setting up the printer on a wireless network.
For information on installing the wireless network adapter, see the instruction sheet that came with the
adapter.
A Service Set Identifier (SSID) is a name assigned to a wireless network. Wired Equivalent Privacy (WEP), Wi-Fi
Protected Access (WPA), WPA2, and 802.1X - RADIUS are types of security used on a network.
Preparing to set up the printer on an Ethernet network
To configure your printer to connect to an Ethernet network, organize the following information before you begin:
Note: If your network automatically assigns IP addresses to computers and printers, continue on to installing the
printer.
A valid, unique IP address for the printer to use on the network
The network gateway
The network mask
A nickname for the printer (optional)
Note: A printer nickname can make it easier for you to identify your printer on the network. You can choose to
use the default printer nickname, or assign a name that is easier for you to remember.
You will need an Ethernet cable to connect the printer to the network and an available port where the printer can
physically connect to the network. Use a new network cable when possible to avoid potential problems caused by a
damaged cable.
Preparing to set up the printer on a wireless network
Notes:
Make sure your wireless network adapter is installed in your printer and working properly.
Make sure your access point (wireless router) is turned on and is working properly.
Make sure you have the following information before setting up the printer on a wireless network:
SSID—The SSID is also referred to as the network name.
Wireless Mode (or Network Mode)—The mode is either infrastructure or ad hoc.
Channel (for ad hoc networks)—The channel defaults to automatic for infrastructure networks.
Some ad hoc networks will also require the automatic setting. Check with your system support person if you are
not sure which channel to select.
Additional printer setup 37

Table of Contents

Other manuals for Lexmark CS510de

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS510de and is the answer not in the manual?

Lexmark CS510de Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Wi-FiNo
Security algorithms802.1x RADIUS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 7000 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Internal memory512 MB
Processor frequency800 MHz
Maximum internal memory2560 MB
Sound pressure level (printing)50 dB
Sound pressure level (quiet mode)46 dB
Total input capacity250 sheets
Total output capacity125 sheets
Maximum input capacity1450 sheets
Total number of input trays1
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (printing)580 W
Package weight24300 g
Networking featuresGigabit Ethernet
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systemsMac OS X 10.5, 10.6, 10.7, 10.8\\r Windows XP (32/64-bit)\\r Windows Server 2003 (32/64-bit)\\r Windows Vista (32/64-bit)\\r Windows Server 2008 (32/64-bit)\\r Windows 7 (32/64-bit)\\r Windows Server 2008 R2\\r Windows 8 (32/64-bit)\\r Windows Server 2012\\r Novell NetWare 6.5 Open Enterprise Server\\r Novell NetWare 5.1 SP6+, 6.0 SP3+\\r Novell Open Enterprise Server\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r ​​Linpus Linux Desktop 9.6\\r Debian GNU / Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu 11.04, 11.10, 12.04\\r openSUSE 11.3, 11.4 , 12.1\\r PCLinuxOS 2011.9\\r Mint 9, 10, 11, 12\\r Fedora 14, 15\\r Sun Solaris SPARC 9, 10\\r HP-UX 11.11, 11.23, 11.31\\r Sun Solaris x86 10, 11\\r IBM AIX 5.3, 6.1, 7.1
Sustainability certificatesENERGY STAR
DisplayLCD
CertificationCSA, ICES, BSMI, FCC, UL, EN, IEC, CE, CCC, CISPIR
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Weight20900 g
Dimensions (WxDxH)442 x 407 x 306 mm
