Page #93 background imageLoading...
Page #93 background image
Settings menu
Setup menu
Use To
Printer Language
PCL Emulation
PS Emulation
Set the default printer language.
Notes:
PS Emulation is the factory default setting. PS Emulation uses
a PS interpreter for processing print jobs.
PCL Emulation uses a PCL interpreter for processing print
jobs.
Setting a printer language as the default does not prevent a
software program from sending print jobs that use another
printer language.
Job Waiting
On
Off
Determine if print jobs are removed from the print queue when
they require unavailable printer options or custom settings. These
print jobs are stored in a separate print queue, so other jobs print
normally. When the missing information or options are obtained,
the stored jobs print.
Notes:
Off is the factory default setting.
This menu item appears only if a non-readonly printer hard
disk is installed. This requirement ensures that stored jobs
are not deleted if the printer loses power.
Print Area
Normal
Fit To Page
Whole Page
Set the logical and physical printable area.
Notes:
Normal is the factory default setting. When attempting to
print data in the nonprintable area defined by the Normal
setting, the printer clips the image.
Fit to Page fits the page content into the selected paper size.
Whole Page allows the image to be moved into the
nonprintable area defined by the Normal setting, but the
printer clips the image at the Normal setting boundary. This
setting affects only pages printed using a PCL 5e interpreter
and has no effect on pages printed using the PCL XL or
PostScript interpreter.
Printer Usage
Max Yield
Max Speed
Set color toner use in printing.
Note: Max Yield is the factory default setting.
Understanding the printer menus 93

Table of Contents

Other manuals for Lexmark CS510de

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS510de and is the answer not in the manual?

Lexmark CS510de Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Wi-FiNo
Security algorithms802.1x RADIUS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 7000 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Internal memory512 MB
Processor frequency800 MHz
Maximum internal memory2560 MB
Sound pressure level (printing)50 dB
Sound pressure level (quiet mode)46 dB
Total input capacity250 sheets
Total output capacity125 sheets
Maximum input capacity1450 sheets
Total number of input trays1
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (printing)580 W
Package weight24300 g
Networking featuresGigabit Ethernet
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systemsMac OS X 10.5, 10.6, 10.7, 10.8\\r Windows XP (32/64-bit)\\r Windows Server 2003 (32/64-bit)\\r Windows Vista (32/64-bit)\\r Windows Server 2008 (32/64-bit)\\r Windows 7 (32/64-bit)\\r Windows Server 2008 R2\\r Windows 8 (32/64-bit)\\r Windows Server 2012\\r Novell NetWare 6.5 Open Enterprise Server\\r Novell NetWare 5.1 SP6+, 6.0 SP3+\\r Novell Open Enterprise Server\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r ​​Linpus Linux Desktop 9.6\\r Debian GNU / Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu 11.04, 11.10, 12.04\\r openSUSE 11.3, 11.4 , 12.1\\r PCLinuxOS 2011.9\\r Mint 9, 10, 11, 12\\r Fedora 14, 15\\r Sun Solaris SPARC 9, 10\\r HP-UX 11.11, 11.23, 11.31\\r Sun Solaris x86 10, 11\\r IBM AIX 5.3, 6.1, 7.1
Sustainability certificatesENERGY STAR
DisplayLCD
CertificationCSA, ICES, BSMI, FCC, UL, EN, IEC, CE, CCC, CISPIR
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Weight20900 g
Dimensions (WxDxH)442 x 407 x 306 mm
