Lexmark CS510de User Manual

Connecting the printer to a wireless network using the Embedded Web Server
Before you begin, make sure that:
• Your printer is connected temporarily to an Ethernet network.
• A wireless network adapter is installed in your printer and working properly. For more information, see the
instruction sheet that came with your wireless network adapter.
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears as four
sets of numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Settings > Network/Ports > Wireless.
3 Modify the settings to match the settings of your access point (wireless router).
Note: Make sure to enter the correct SSID.
4 Click Submit.
5 Turn off the printer, and then disconnect the Ethernet cable. Then wait for at least five seconds, and then turn the
printer back on.
6 To verify if your printer is connected to the network, print a network setup page. Then in the Network Card [x]
section, see if the status is “Connected”.
For more information, see the “Verifying printer setup” section of the User’s Guide.
Verifying printer setup
When all hardware and software options are installed and the printer is turned on, verify that the printer is set up
correctly by printing the following:
• Menu settings page—Use this page to verify that all printer options are installed correctly. A list of installed options
appears toward the bottom of the page. If an option you installed is not listed, then it is not installed correctly.
Remove the option and install it again.
• Network setup page—If your printer is connected to a network or connected to a print server, print a network
setup page to verify the network connection. This page also provides important information that aids network
printing configuration.
Printing a menu settings page
From the home screen, navigate to:
> Reports > Menu Settings Page
Additional printer setup 40

Lexmark CS510de Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Wi-Fi	No
Security algorithms	802.1x RADIUS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 7000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Internal memory	512 MB
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	50 dB
Sound pressure level (quiet mode)	46 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	1450 sheets
Total number of input trays	1
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (printing)	580 W
Package weight	24300 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Mac OS X 10.5, 10.6, 10.7, 10.8\\r Windows XP (32/64-bit)\\r Windows Server 2003 (32/64-bit)\\r Windows Vista (32/64-bit)\\r Windows Server 2008 (32/64-bit)\\r Windows 7 (32/64-bit)\\r Windows Server 2008 R2\\r Windows 8 (32/64-bit)\\r Windows Server 2012\\r Novell NetWare 6.5 Open Enterprise Server\\r Novell NetWare 5.1 SP6+, 6.0 SP3+\\r Novell Open Enterprise Server\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r ​​Linpus Linux Desktop 9.6\\r Debian GNU / Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu 11.04, 11.10, 12.04\\r openSUSE 11.3, 11.4 , 12.1\\r PCLinuxOS 2011.9\\r Mint 9, 10, 11, 12\\r Fedora 14, 15\\r Sun Solaris SPARC 9, 10\\r HP-UX 11.11, 11.23, 11.31\\r Sun Solaris x86 10, 11\\r IBM AIX 5.3, 6.1, 7.1
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CSA, ICES, BSMI, FCC, UL, EN, IEC, CE, CCC, CISPIR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Weight	20900 g
Dimensions (WxDxH)	442 x 407 x 306 mm
