Use To
Search for networks Show available wireless connections.
Note: This menu shows all broadcast secured or unsecured SSIDs.
Enter a network name Manually type the SSID.
Note: Make sure to type the correct SSID.
WiFi Protected Setup Connect the printer to a wireless network using WiFi Protected Setup.
3 Follow the instructions on the printer display.
Connecting the printer to a wireless network using WiFi Protected Setup
Before you begin, make sure that:
The access point (wireless router) is WiFi Protected Setup (WPS) certified or WPScompatible. For more
information, see the documentation that came with your access point.
A wireless network adapter installed in your printer is attached and working properly. For more information, see
the instruction sheet that came with the wireless network adapter.
Using the Push Button Configuration method
1
From the printer control panel, navigate to:
> Network/Ports > Network [x] > Network [x] Setup > Wireless > Wireless Connection Setup > WiFi Protected
Setup > Start Push Button Method
2 Follow the instructions on the printer display.
Using the Personal Identification Number (PIN) method
1
From the printer control panel, navigate to:
> Network/Ports > Network [x] > Network [x] Setup > Wireless > Wireless Connection Setup > WiFi Protected
Setup > Start PIN Method
2 Copy the eightdigit WPS PIN.
3 Open a Web browser, and then type the IP address of your access point in the address field.
Notes:
The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.
If you are using a proxy server, then temporarily disable it to load the Web page correctly.
4 Access the WPS settings. For more information, see the documentation that came with your access point.
5 Enter the eightdigit PIN, and then save the setting.
Additional printer setup 39

Table of Contents

Other manuals for Lexmark CS510de

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS510de and is the answer not in the manual?

Lexmark CS510de Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Wi-FiNo
Security algorithms802.1x RADIUS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 7000 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, PPDS
Internal memory512 MB
Processor frequency800 MHz
Maximum internal memory2560 MB
Sound pressure level (printing)50 dB
Sound pressure level (quiet mode)46 dB
Total input capacity250 sheets
Total output capacity125 sheets
Maximum input capacity1450 sheets
Total number of input trays1
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (printing)580 W
Package weight24300 g
Networking featuresGigabit Ethernet
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systemsMac OS X 10.5, 10.6, 10.7, 10.8\\r Windows XP (32/64-bit)\\r Windows Server 2003 (32/64-bit)\\r Windows Vista (32/64-bit)\\r Windows Server 2008 (32/64-bit)\\r Windows 7 (32/64-bit)\\r Windows Server 2008 R2\\r Windows 8 (32/64-bit)\\r Windows Server 2012\\r Novell NetWare 6.5 Open Enterprise Server\\r Novell NetWare 5.1 SP6+, 6.0 SP3+\\r Novell Open Enterprise Server\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r ​​Linpus Linux Desktop 9.6\\r Debian GNU / Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu 11.04, 11.10, 12.04\\r openSUSE 11.3, 11.4 , 12.1\\r PCLinuxOS 2011.9\\r Mint 9, 10, 11, 12\\r Fedora 14, 15\\r Sun Solaris SPARC 9, 10\\r HP-UX 11.11, 11.23, 11.31\\r Sun Solaris x86 10, 11\\r IBM AIX 5.3, 6.1, 7.1
Sustainability certificatesENERGY STAR
DisplayLCD
CertificationCSA, ICES, BSMI, FCC, UL, EN, IEC, CE, CCC, CISPIR
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Weight20900 g
Dimensions (WxDxH)442 x 407 x 306 mm
