The following table lists the maximum weights supported by the trays and the multipurpose feeder.
Overview of card stock and label support
Tray 1 Trays 2 and 3 Multipurpose feeder
Labels Not applicable Not applicable
220 g/m
2
Card stock
105 g/m
2
220 g/m
2
220 g/m
2
Media specifications
Labels Width: 210–216 mm (8.3–8.5 in.)
Length: 279–356 mm (11–11.7 in.)
Weight:
120–128 g/m
2
Thickness: 0.13–0.20 mm (0.005–0.008 in.)
Smoothness: 100–400 Sheffield*
* 150–250 Sheffield is optimal. Using media higher than 300 Sheffield could result in print quality
degradation.
Card stock Width: 210–216 mm (8.3–8.5 in.)
Length: 279–356 mm (11–11.7 in.)
Weight:
Up to 220 g/m
2
Card stock and label guidelines
When printing on labels:
• Load labels only on the multipurpose feeder.
• From the printer control panel, set Paper Type to Labels in the Paper Menu.
• Do not use label sheets with a slick backing material.
• Do not print within 1 mm (0.04 in.) of the die‑cut, the edge of the label or the perforations, or between the die‑cuts.
• Use full label sheets. Partial sheets may cause labels to peel off during printing, resulting in a paper jam.
• Do not use label sheets that have adhesive to the edge of the sheet. We recommend zone coating of the adhesive
at least 1 mm (0.04 in.) away from the edges. Adhesive material may contaminate your printer and could void your
warranty.
When printing on card stock:
• From the printer control panel, set Paper Type to Card Stock.
• Do not use creased card stock. It may cause paper jams.
• We recommend the use of grain long card stock.
Printer specifications 63
