Parts Catalog 4-5

4510-001

Assembly 2: Engine

Asm-

Index

Part

Number

Unit Description

2-1 12G6795 1 Printhead Assembly Complete

2 12G6256 1 Plate, Printhead Mount

3 12G6784 1 Shaft, Pick Roller

4 12G6777 1 Plate, Lift

5 12G6259 1 Bushing, Transfer Roll Right

6 12G6262 1 Spring, Bushing, Right

7 12G6269 1 Housing, Transfer Roll Bushing

8 12G6785 1 Pad, Left Separator

9 12G6786 1 Pad, Right Separator

10 12G6778 1 Holder, Pad

11 12G6779 1 Pad, Main Separator

12 12G6769 1 Frame, Lower

13 12G6783 1 Solenoid, Pick Roller Clutch

14 12G6780 1 Clutch Assembly, Pick Roller Gear

15 12G6265 1 Bushing, Shaft

16 12G6771 1 Fan, Cooling

17 12G6266 1 Roller, Paper Feed

18 12G6798 1 Motor, Main

19 12G6794 1 Drive Assembly, Main

20 12G6799 1 Cable, Main Motor

22 12G6782 1 Card Assembly, Input/Exit Sensor

23 12G6267 1 Housing, Paper Feed Roller

24 12G6789 1 Flag, Exit Sensor

25 12G6788 1 Flag, Input Sensor

26 12G6263 1 Holder, Exit Roller

27 12G6257 1 Switch, Cover Open
