Parts Catalog 4-7
4510-001
Assembly 2 (cont.): Engine
Asm-
Index
Part
Number
Unit Description
2-28 12G6787 1 Roll Assembly, Pick
29 12G6781 1 Contact Assembly, Toner Cartridge
30 12G6770 1 Roller, Transfer
31 12G6261 1 Spring, Bushing, Left
32 12G6260 1 Bushing, Transfer Roll Left
33 12G6258 1 Card Assembly, Pre-Transfer LED
34 12G6264 1 Cover, PTL Board
35 12G6797 1 Cable, Printhead
