Lexmark E460DN Service Manual

2-16 Service Manual
4513-630, -63W, -6EW
922.04 Hot roll timed out in trying to reach the final lamp
detection temperature.
Replace the fuser. See “Fuser service check”
on page 2-26.
922.05 Did not roll over to a steady state control in time after the
hot roll lamp detection.
922.06 Hot roll did not reach the operating temperature in time
(new enhanced control).
922.07 Media reached fuser nip, and fuser is under temperature
922.08 Fuser warm-up failure (motor start condition)
922.09 Fuser warm-up failure (compression set)
922.20 Belt fuser failed to reach the preheat temperature for the
motor to start during warm-up.
922.21 Belt fuser was under temperature when the media
reached the fuser nip.
923.00 Fuser is over temperature.
923.01 Fuser is over temperature. This applies to the fuser and
belt fusers.
924.00 Open thermistor check.
924.01 Open thermistor check failure. This applies to the fuser
and belt fusers.
924.02 Open thermistor check failure. The ADC failed to
converge. Possible noisy thermistor signal. This applies
to the fuser and belt fusers.
925.xx Wrong fuser installed. The fuser type stored in the
cartridge ID does not match the actual fuser installed in
the printer.
Fan service errors
927.00 Service fan error Replace the fan. See “Cooling fan service
check” on page 2-24.
927.03 Main fan took too long to ramp up
927.04 Main fan is under speed or stalled during speed
adjustment state
927.05 Main fan overspeed during speed adjustment state.
927.06 Main fan capture data is invalid, and speed control is at
maximum in fan control idle state
927.07 Main fan capture data is invalid, and speed control is at
maximum in fan control adjustment state.
Toner service errors
929.00 Toner sensor error Remove the toner cartridge, and shake it Try a
different toner cartridge, if possible. If the error
persists, then replace the toner level sensor. See
“Toner level sensor removal” on page 4-64.
929.01 No home window
929.02 No sensor transition (closed)
929.03 No sensor transition (open)
Error Description Action

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
