Lexmark E460DN Service Manual

Diagnostics information 2-17
4513-630, -63W, -6EW
Printhead service errors
930.00 Wrong printhead installed Replace the printhead. See “Printhead service
check” on page 2-38.
931.00 No first hsync
931.01 No first hsync
932.00 Lost hsyncs
932.01 Lost hsyncs
933.01 Printhead boost signal failure
934.00 Mirror motor lost lock.
934.01 Mirror motor lost lock.
935.00 No initial mirror motor lock
935.01 Timed out waiting for mirror motor lock
935.10 Printhead sweep error, swept through Hz range without
finding the resonant frequency
935.12 Printhead sweep error, coarse sweep state
935.15 Printhead open-loop error, check prelim amp state
935.16 Printhead open-loop error, enable amp Kp state
935.17 Printhead closed-loop error, amp Kp failed to converge
935.18 Printhead closed-loop error, enable amp Ki state
935.19 Printhead closed-loop error, amp Ki failed to converge
935.20 Printhead closed-loop error, enable offset controller
state
935.21 Printhead closed-loop error, load scan regs state
935.22 Printhead closed-loop error, fwd and rev capture times
differ by too much
935.23 Printhead closed-loop error, check sweep accuracy
state
935.25 Printhead closed-loop error, off-resonant PI effort state
935.26 Timed out on POR sweep
935.27 Exceeded maximum open loop drive level when
configuring for sweep re-try.
935.28 Exceeded maximum open loop drive level when setting
operating Hz.
Transport motor service errors
Error Description Action

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
