Lexmark E460DN Service Manual

2-18 Service Manual
4513-630, -63W, -6EW
936.01 No lock detected at normal motor start Replace the main motor gear drive. See “Main
motor service check” on page 2-27
936.02 No lock detected at motor start for motor ID
936.03 No halls detected at motor start
936.04 Failed to stop within timeout Replace the main motor gear drive. See “Main
motor service check” on page 2-27
936.05 Stall detected during speed control
937.00 Main transport motor lost lock
937.01 Main transport motor lost lock, detected by engine
control
937.02 Overspeed detected during position control
937.03 Overspeed detected during speed control
Power supply service errors
940.00 LVPS service error Replace the LVPS/HVPS. See “LVPS/HVPS
service check” on page 2-26.
940.01 Line frequency outside allowed range of 45Hz-64Hz
940.02 Line frequency below 43Hz
940.03 No zero cross detected on belt fuser model
Controller board and operator panel service errors
948.xx Failed engine board Replace the controller board. See “Controller
board service check” on page 2-23.
949.xx
950.xx Mismatch between EEPROM and mirror memory
Note: A new controller board or operator panel has been
installed, and has not been properly prepared for this
use. Install a new note. Do not install both the controller
board and the operator panel at the same time without a
POR in between.
Install a new controller bored or operator panel.
See “Controller board service check” on
page 2-23 or “Operator panel service check”
on page 2-28.
951.xx Error with secure NVRAM on the controller board Replace the controller board. See “Controller
board service check” on page 2-23.
952.xx A recoverable MVRAM Cyclic Redundancy Check error
occurred.
Performing POR will clear this error.
953.xx NVRAM chip failure with mirror Replace the operator panel. See “Operator
panel service check” on page 2-28.
954.xx NVRAM chip failure with system part. Replace the controller board. See “Controller
board service check” on page 2-23.
955.xx The code ROM or NAND flash failed the Cyclic
Redundancy Check or the NAND experienced an
uncorrectible multi-bit failure.
956.00 RIP card failure: processor failure
956.01 Processor overtemp
957.xx RIP card failure: ASIC failure
958.xx Printer has performed more than 100 “shift and reflash”
operations as a result of ECC bit corrections
Error Description Action

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
