Lexmark E460DN Service Manual

Diagnostics information 2-19
4513-630, -63W, -6EW
Firmware or controller board errors
959.01 Controller verification failure of pensive boot code Call the next level of support to update the
firmware, or replace the controller board. See
“Controller board service check” on
page 2-23.
959.02 Failure to authenticate Signature Verification Code
959.03 Signature Verification Code failed to authenticate a code
partition.
Update firmware and call the next level of
support, or replace the controller board. See
“Controller board service check” on
page 2-23.
959.04 Jump to unverified address
959.05 Unknown boot failure Update firmware and call the next level of
support, or replace the controller board. See
“Controller board service check” on
page 2-23
959.20 Pensive hardware failure Replace the controller board. See “Controller
board service check” on page 2-23.
959.21 Pensive did not respond to command request.
959.22 Challenge secret failure
959.23 Pensive self test failed during initialization. Replace the controller board. See “Controller
board service check” on page 2-23.
959.24 EEPROM retention error
959.25 Insufficient device space during HW prog
959.26 Incremental counter reset exceeds maximum value
959.27 Increment count failed due to max value limit
959.28 Invalid SP memory configuration
Memory and emulation errors
960.xx RAM memory error: RAM soldered on the controller
board is bad
Replace the controller board. See “Controller
board service check” on page 2-23.
961.xx RAM memory error: memory card in slot is bad. Replace the memory card.
964.xx Download Emulation Cyclic Redundancy Check Error:
checksum failure detected in the emulation header or
emulation file.
Disable the Download Emulation. Program the
download emulation into the firmware card again.
If this does not resolve the problem, then replace
the firmware card and download the emulation
again.
Network errors
975.xx Unrecognizable network Call the next level of support.
976.xx Unrecoverable software error in network port
978.xx Bad checksum while programming network port
979.xx Flash parts failed while programing network port
Other errors
Error Description Action

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
