Page #144 background imageLoading...
Page #144 background image
146 errors
146 error messages
Error code Description Action
146.00 Autocompensator Pick/Lift Motor—Encoder
Never Detected in tray 1.
Go to
“Tray 1 pick/lift motor gearbox service
check” on page 144.
Tray 1 pick/lift motor gearbox service check
Action Yes No
Step 1
a Remove Tray 1.
b Check the lift plate and gears for proper operation by moving
the metal plate.
Do the lift plate and gears move freely, and are they free of wear
or damage?
Go to step 2. Replace the tray
insert.
Step 2
Check the pick/lift motor gearbox for the following:
Gear tooth breakage
Freedom of rotation
Is it free of wear or damage?
Go to step 3. Replace the pick/lift
motor gearbox. See
“Pick/Lift motor
gearbox removal”
on page 305.
Step 3
Check the cable JLIFT1 on the controller board.
Is it properly connected and free of damage?
Go to step 4. Replace the pick/lift
motor gearbox. See
“Pick/Lift motor
gearbox removal”
on page 305.
Step 4
Replace the controller board.
Does this fix the problem?
The problem is
solved.
Contact the next
level of support.
155 errors
155 error messages
Error code Description Action
155.00 No encoder received from auger motor. Go to
“Cartridge gearbox service check” on
page 145.
4514-6xx
Diagnostics and troubleshooting
144
