Error code Description Action
202.17 Page at fuser nip before fuser reached acceptable
operating temperature. Page arrived at fuser
earlier than expected, so it was probably staged.
Go to
“Sensor (fuser exit) jam service check” on
page 97.
202.22 Cartridge Motor - Motor Underspeed Error. Motor
made it to closed loop steady state, but then
detected speed was below threshold.
Go to
“Sensor (fuser exit) jam service check” on
page 97.
202.28 Exit sensor bounce issue. Go to
“Sensor (fuser exit) jam service check” on
page 97.
202.32 The sheet is too long to be duplexed. The blow
through is enabled.
Go to
“Duplex service check” on page 98.
202.36 Long paper or shingled multi feed stopped before
sending to duplex.
Go to
“Duplex service check” on page 98.
202.43 During warm up flush, media that passed the input
sensor failed to reach the exit sensor.
Go to
“Sensor (fuser exit) jam service check” on
page 97.
202.45 During warm up flush, sheet detected too long
over exit sensor.
Go to
“Sensor (fuser exit) jam service check” on
page 97.
Sensor (fuser exit) jam service check
Action Yes No
Step 1
Check the input sensor area for jammed media fragments.
Is the paper path free of partially fed or jammed media?
Go to step 2. Clear the paper path
of any media
fragments.
Step 2
Check the fuser exit sensor cable JEXIT1 for proper connection.
Is it properly connected?
Go to step 3. Reseat the cable.
Step 3
POR into the Diagnostics menu and perform a sensor test:
Diagnostics Menu > Base Sensor Test > Exit
Does the sensor state on the control panel display change when
it is toggled?
Go to step 4. Replace the fuser.
See
“Fuser
removal” on
page 314.
Step 4
Check the fuser gears and rollers for damage.
Are they free of damage?
Go to step 5. Replace the fuser.
See
“Fuser
removal” on
page 314.
Step 5
Does the error remain?
Contact the next
level of support.
The problem is
solved.
4514-6xx
Diagnostics and troubleshooting
97
