2-2. Instrument cluster

n Display contents

Trip information contents Switching display items

Current fuel consumption

Pressing the “ENTER” switch

upwards or downwards.

Average fuel consumption after

refueling

Average fuel consumption

Average vehicle speed

Cruising range

Multi-information display OFF

Eco Driving Indicator Zone Dis-

play
