504
4-3. Do-it-yourself maintenance
35
AFS 7.5 A Adaptive front-lighting system
36
BK/UP LP 7.5 A Back-up lights
37
HEATER NO. 2 7.5 A Air conditioning system, AWD system
38
ECU IG1 10 A
Adaptive front-lighting system, head-
light cleaner, cooling fan, cruise con-
trol, vehicle stability control, vehicle
dynamics integrated management
39
EFI NO. 2 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
40
F/PUMP 15 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
41
DEICER 25 A Windshield wipers and washer
42
STOP 7.5 A
Vehicle stability control, vehicle
dynamics integrated management,
high mounted stoplight
43
TOWING BATT 20 A Trailer battery
44
TOWING 30 A Trailer lights
45
FILTER 10 A Condenser
46
IG1 MAIN 30 A
ECU IG1, BK/UP LP,
HEATER NO. 2, AFS
47
H-LP RH HI 15 A Right-hand headlight (high beam)
48
H-LP LH HI 15 A Left-hand headlight (high beam)
49
BIXENON 10 A Discharge headlight
50
H-LP RH LO 15 A Right-hand headlight (low beam)
51
H-LP LH LO 15 A Left-hand headlight (low beam)
Fuse Ampere Circuit
To Next Page
