506
4-3. Do-it-yourself maintenance
6
ECU-IG1 NO. 3 10 A
Outside rear view mirror, windshield
wipers and washer, seat heaters,
starter system, power outlet, moon
roof, Automatic High Beam
7
ECU-IG1 NO. 1 10 A
Multiplex communication system,
electric power steering system, shift
lock control system, tilt and telescopic
steering, starter system, automatic
transmission system, power back
door, tire pressure warning system
8
S/ROOF 30 A Moon roof
9
FUEL OPN 7.5 A Fuel filler door opener
10
PSB 30 A Pre-collision seat belt
11
TI & TE 30 A Tilt and telescopic steering system
12
DR LOCK 10 A Power door lock system
13
FR FOG 15 A Front fog lights
14
P-SEAT LH 30 A Power seat (left-side)
15
4WD 7.5 A AWD system
16
INVERTER 20 A
17
RR FOG 7.5 A
18
D/L ALT B 25 A Multiplex communication system
19
HEATER 10 A Air conditioning system
20
ECU-IG1 NO. 2 10 A
Air conditioning system, multiport fuel
injection system/sequential multiport
fuel injection system, SRS airbag sys-
tem, multi-information display
Fuse Ampere Circuit
To Next Page
