Lexus LS500 - Page 283

283
4-5. Using the driving support systems
LS500h_OM_OM50F42U_(U)
4
Driving
Hybrid system output
Braking force
Time
Hybrid system output restriction control begins operating
System determines that possibility of collision with detected object is high
Hybrid system output reduced
Example: Multi-infomation display:
“BRAKE!”
 Figure 3 When brake control operates
Hybrid system output
Braking force
Time
A
B
C
D
E
F
G
A
B
C
