Lexus LS500 - Driving Support System Display Area; Pop-Up Display

95
2-1. Instrument cluster
LS500h_OM_OM50F42U_(U)
2
Vehicle status information and indicators
Displays the operational status of the
following systems:
 LTA (Lane Tracing Assist) (if
equipped) (→P.230)
 LKA (Lane-Keeping Assist) (if
equipped) (→P.240)
 Dynamic radar cruise control with
full-speed range (→P.250)
Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display. For
details, refer to the explanation of each sys-
tem.
Pop-up displays for the following sys-
tems will be displayed when necessary.
■ Driving support systems
Displays a warning/suggestion/advice
message or the operating state of a rel-
evant system.
 PCS (Pre-Collision System)
(→P.209, 220)
 FCTA (Front Cross Traffic Alert) (if
equipped) (→P.227)
 Intuitive parking assist (→P.266)
 Parking Support Brake function (for
static objects) (→P.286)
 Brake Override System (→P.159)
 Drive-Start Control (→P.159)
Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display. For
details, refer to the explanation of each sys-
tem.
■ / icons
These icons are linked to the
multi-information display
: Master warning icon
Displayed when a warning message is dis-
played on the multi-information display.
(→P.437)
: Information icon
Displayed when a suggestion pop-up dis-
play (→P.91) or advice pop-up display is
displayed on the multi-information display.
■ Warning message
Some warning messages are displayed
when necessary, according to certain
conditions.
Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display.
■ Audio system operation status
Displayed when an audio remote con-
trol switch on the steering wheel is
operated.
■ Hands-free system status
Displayed when the hands-free system
is operated.
■ When a pop-up display is displayed
When a pop-up display is displayed, a cur-
rent display may no longer be displayed. In
this case, the display will return after the
pop-up display disappears.
Driving support system display
area
Pop-up display
