LG 34UM88C-P User Manual

14
ENGLISH
USING THE MONITOR
• The following instructions are based on the 34UM88
model. Illustrations in this manual may differ from the
actual product.
Press the joystick button, go to Menu → Quick Settings →
Input, and then select the input option.
CAUTION
• Do not press the screen for a prolonged time. This may
cause image distortion.
• Do not display a still image on the screen for a prolonged
time. This may cause image retention. Use a screensaver if
possible.
NOTE
• When connecting the power cord to the outlet, use a
grounded (3-hole) power strip or a grounded power outlet.
• The monitor may flicker when turned on in an area where
the temperature is low. This is normal.
• Sometimes red, green, or blue spots may appear on the
screen. This is normal.
Connecting to a PC
• This monitor supports the *Plug and Play feature.
* Plug and Play: A feature that allows you to add a device to
your computer without having to reconfigure anything or
install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your PC to the
monitor. Connect your PC to the monitor using the HDMI
cable as shown in the illustration below.
DP OUT
NOTE
• Make sure to use the supplied HDMI cable of the product.
Otherwise, this may cause the device to malfunction.
• Use a certified cable with the HDMI logo attached. If you
do not use a certified HDMI cable, the screen may not
display or a connection error may occur.
• Recommended HDMI cable types
- High-Speed HDMI®/
TM
cable
- High-Speed HDMI®/
TM
cable with Ethernet
CAUTION
• Connecting your PC to the monitor using the HDMI cable
may cause device compatibility issues.
• Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may
cause compatibility issues.

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	252.4 mm
Height (with stand)	428.9 mm
Weight (with stand)	8400 g
Depth (without stand)	49.2 mm
Width (without stand)	829.9 mm
Height (without stand)	379.8 mm
Weight (without stand)	6300 g
