LG 34UM88C-P User Manual

20
ENGLISH
Quick Settings
1 To view the OSD menu, press the joystick button at the bottom of
the monitor and then enter the Menu.
2 Go to Quick Settings by moving the joystick.
3 Configure the options following the instructions that appear in the
bottom right corner.
4 To return to the upper menu or set other menu items, move the
joystick to or pressing ( / Ok) it.
5 If you want to exit the OSD menu, move the joystick to until you
exit.
Quick Settings
Quick Settings
Brightness
100 >
Contrast
70 >
PBP
Volume
30 >
Input HDMI1 >
Ratio Wide >
Sound
General
Reset
/ : Move
/ : Ok
: Back
Each option is described below.
Menu > Quick
Settings
Description
Brightness
Adjusts the color contrast and brightness of the screen.
Contrast
Volume Adjusts the volume level.
NOTE
• You can adjust Mute / Unmute by moving the joystick button to in the Volume menu.
Input Selects the input mode.
Ratio Adjusts the aspect ratio of the screen.
Wide Displays the video in widescreen, regardless of the video signal input.
Original Displays video according to the aspect ratio of the video signal input.
Cinema1 Enlarges the screen with an aspect ratio of 21:9. (at 1080p)
Cinema2 Enlarges the screen with an aspect ratio of 21:9, including the black box at the
bottom for subtitles. (at 1080p)
1:1 The aspect ratio is not adjusted from the original.
NOTE
• The display may look the same for Wide, Original, and 1:1 options at the recommended resolution (3440 x 1440).

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	252.4 mm
Height (with stand)	428.9 mm
Weight (with stand)	8400 g
Depth (without stand)	49.2 mm
Width (without stand)	829.9 mm
Height (without stand)	379.8 mm
Weight (without stand)	6300 g
