LG 34UM88C-P User Manual

31
ENGLISH
PRODUCT SPECIFICATION
34UM88, 34UB88
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort)
8-bit / 10-bit color is supported.
Thunderbolt ( )
Pixel Pitch 0.2325 mm x 0.2325 mm
Resolution Max Resolution
3440 x 1440 @ 60 Hz
Recommended
Resolution
Video Signal Horizontal Frequency 30 kHz to 90 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Separate Sync.
Input Connector
H/P OUT, HDMI IN 1, HDMI IN 2, DP (DisplayPort) IN, Thunderbolt ( ) x 2, USB UP, USB ( ) 1, 2
Power Sources Power Rating 19 V 5.6 A
Power Consumption
(Typical)
34UM88 Operating Mode:
70 W (Typical, USB excluded) (Outgoing condition)*
56.73 W (ENERGY STAR® standard)**
34UB88 Operating Mode:
47.9 W (Typical, USB excluded) (Outgoing condition)*
32.8 W (ENERGY STAR® standard)**
Sleep Mode ≤ 1.2 W
Off Mode ≤ 0.3 W
AC/DC Adapter ADS-110CL-19-3 190110G type, manufactured by Honor
Output: 19 V 5.79 A
Environmental
Conditions
Operating Conditions Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity Less than 80 %
Storing Conditions Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Humidity Less than 85 %
Dimensions Monitor Size (Width x Height x Depth)
With Stand 829.9 mm x 428.9 mm x 252.4 mm
(32.6 inches x 16.8 inches x 9.9 inches)
Without Stand 829.9 mm x 379.8 mm x 49.2 mm
(32.6 inches x 14.9 inches x 1.9 inches)
Weight (Without
Packaging)
With Stand 8.4 kg (18.5 lbs)
Without Stand 6.3 kg (13.8 lbs)
Specifications are subject to change without notice.
* The Operating Mode of Power Consumption is measured with LGE test standard. (Full White pattern, Maximum resolution)
** The Power Consumption level can be different by operating condition and monitor setting.
** The Operating Mode of Power Consumption is measured with ENERGY STAR® test standard.

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	252.4 mm
Height (with stand)	428.9 mm
Weight (with stand)	8400 g
Depth (without stand)	49.2 mm
Width (without stand)	829.9 mm
Height (without stand)	379.8 mm
Weight (without stand)	6300 g
