LG 34UM88C-P User Manual

26
ENGLISH
General
1 To view the OSD menu, press the joystick button at the bottom of
the monitor and then enter the Menu.
2 Go to General by moving the joystick.
3 Configure the options following the instructions that appear in the
bottom right corner.
4 To return to the upper menu or set other menu items, move the
joystick to or pressing ( / Ok) it.
5 If you want to exit the OSD menu, move the joystick to until you
exit.
General
Quick Settings
Language English >
SMART ENERGY SAVING Low >
PBP
Power LED Off >
Automatic Standby Off >
DisplayPort 1.2 Disable >
Quick Charge Off >
Sound
Buzzer On >
OSD Lock Off >
General
Reset
/ : Move
/ : Ok
: Back
Each option is described below.
Menu > General Description
Language Sets the menu screen to the desired language.
SMART ENERGY
SAVING
Conserve energy by using luminance compensation algorithm.
High Saves energy using the high-efficiency SMART ENERGY SAVING feature.
Low Saves energy using the low-efficiency SMART ENERGY SAVING feature.
Off Disables the SMART ENERGY SAVING feature.
Power LED Turns the power LED on the front of the monitor On or Off.
On The power LED turns on automatically.
Off The power LED turns off.
Automatic
Standby
Feature that automatically turns off the monitor when there is no movement on the screen for a period
of time. You can set a timer for the auto-off function. (Off, 4 H, 6 H, and 8 H)
DisplayPort 1.2 Enables or disables DisplayPort 1.2.
NOTE
• Be sure to configure this option according to the DisplayPort version supported by your graphics card.
Set this option to Disable if your graphics card does not support DisplayPort 1.2.
• When DisplayPort 1.2 is disabled, you cannot use the 10-bit output of your video card.

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	252.4 mm
Height (with stand)	428.9 mm
Weight (with stand)	8400 g
Depth (without stand)	49.2 mm
Width (without stand)	829.9 mm
Height (without stand)	379.8 mm
Weight (without stand)	6300 g
