ENGLISH

User Settings

Menu Settings

1 To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu.

2 Configure the options by moving the joystick up/down/left/right.

3 To return to the upper menu or set other menu items, move the joystick to or pressing ( / Ok) it.

4 If you want to exit the OSD menu, move the joystick to until you exit.

• When you enter the menu, instructions on how to use the button will appear in the bottom right corner of the screen.

Quick Settings PBP Picture Sound General Reset

Each option is described below.

Menu Description

Quick Settings Brightness

Adjusts the color contrast and brightness of the screen.

Contrast

Volume Adjusts the volume level.

NOTE

• You can adjust Mute / Unmute by moving the joystick button to in the Volume

menu.

Input Selects the input mode.

Ratio Adjusts the aspect ratio of the screen.

PBP PBP Displays the screens of two input modes on one monitor.

Picture Picture Mode Changes the picture mode to the one optimized for a given feature.

Picture Adjust Adjusts the Sharpness, Black Level, and DFC.

Game Adjust Adjusts the Response Time, FreeSync, and Black Stabilizer.

Color Adjust Adjusts the Gamma, Color Temp, and Six Color.

Sound Adjusts the MaxxAudio, MaxxAudio Settings, and Midnight Mode.

General Sets Language, SMART ENERGY SAVING, Power LED, Automatic Standby,

DisplayPort 1.2, Quick Charge, Buzzer, and OSD Lock.

Reset Restores the default settings.

Exit Exits the OSD menu.

CAUTION

• Your monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.

Questions and Answers:

Need help?

Do you have a question about the LG 34UM88C-P and is the answer not in the manual?

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI
