LG 34UM88C-P User Manual

17
ENGLISH
HDMI/DP (DisplayPort) connection
To use USB 3.0, connect the A-B type USB 3.0 cable of the
product to the PC.
Peripheral devices connected to the USB IN port can be
controlled from the PC.
DP OUT
(sold separately)
(sold separately)
Thunderbolt connection
Peripheral devices connected to the USB IN port can be
controlled from the PC.
If you change the input on the menu while a device is in
connection via the Thunderbolt ( ) port, then the device in
connection via the USB port may not work properly.
34UM88, 34UB88
(sold separately)
DP OUT
(sold separately)
Connecting Headphones
Connect peripherals to the monitor via the headphones port.
Connect as illustrated.
DP OUT
(sold separately)
NOTE
• Peripheral devices are sold separately.
• If you use angled earphones, it may cause a problem
with connecting another external device to the monitor.
Therefore, it is recommended to use straight earphones.
Angled
Straight
• Depending on the audio settings of the PC and external
device, headphones and speaker functions may be limited.

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	252.4 mm
Height (with stand)	428.9 mm
Weight (with stand)	8400 g
Depth (without stand)	49.2 mm
Width (without stand)	829.9 mm
Height (without stand)	379.8 mm
Weight (without stand)	6300 g
